BTR LS PDS Stage 4 Camshaft V2. Sold as described below; installation labor and tuning are not included.
BTR PDS STAGE 4 CAMSHAFT V2
229/25X, .636"/.636", 116 LSA
INTAKE LOBE LIFT @ TDC: 0.05129
The most aggressive camshaft Brian Tooley Racing offers for GM LSA & LS9 engines. This cam is recommended when looking for more power than our Stage III application offers and has an ultra-aggressive idle. It is perfect for use in high rpm Max Effort stock displacement ,or 4" stroker applications when paired with a Magnuson 2650 or Whipple 3.0 PDS superchargers.
We recommend the use of aftermarket or ported OEM cylinder heads and larger throttle bodies when used with higher boost levels.
This cam uses ultra stable lobes for higher RPM potential, and has proven to be extremely durable in testing.
- Manufacturer part number: BTR-PDSSTAGE4
- Brand: Brian Tooley Racing
- Part Type: Camshaft
- Engine Type: LSA/LS9
- Engine Combination: SUPERCHARGED - ROOTS
- Camshaft Style: HYDRAULIC ROLLER
- Cam Bolt Style: THREE BOLT
Match this part to your exact engine, cylinder heads, and intended use. Verify required clearances, spring setup, and measured pushrod length before installation. Cam stages are specific to their cam family.
Shipping: Lower-48 ground shipping is $19.99 per order. Use CAMSHIP199 for free cam-parts ground shipping on orders of $199 or more. Free shop pickup is available after your order is confirmed ready.
